• Dual module SIMs for network load balancing and redundancy

• Wi-Fi compliant IEEE 802.11b/g/n/ac dual-band for mobile client connectivity

• 5-port Gigabit Ethernet, built-in redundant VRRP protocol

• 2 DI, 1DO and 1 serial console port (RS232 or RS485) for Modbus applications

• Multiple VPNs with IPSEC, OpenVPN, PPTP, L2TP, GRE and VPN Failover

• Full security with VLAN, NAT,DMZ, Static routing, firewall and IP/MAC/port filtering

• Supports CMS for remote management

• -35 to 75 degrees C operating temperature and fanless design



Physical Ports:

• 4x 10/100/1000BASE-T RJ45 LAN ports, auto-negotiation, auto MDI/MDI-X
• 1x 10/100/1000BASE-T RJ45 WAN port, auto-negotiation, auto MDI/MDI-X
• 2x 4G LTE antennas
• 1x 2.4G/5G WiFi antenna
• 2x SIM card slots
• 1x serial console port (RS232 or RS485)
• 1x reset button
• 1x MicroSD slot to save files for serial port data

Cellular Interface:

• Supports multi-band connectivity with FDD LTE/ TDD LTE/ WCDMA/ GSM/ LTE Cat4
• Supports failover and load balancing
• Built-in SIM and broadband backup for network redundancy
• Two detachable antennas for 4G LTE connection
• LED indicators for signal strength and connection status

Wi-Fi Interface:

• Complies with IEEE 802.11b/g/n/ac 2.4/5GHz
• Supports AP, Client, Repeater and Repeater Bridge modes
• One detachable dual band antenna for wireless connection
• 64/128-bit WEP, WPA/WPA2 with TKIP/AES encryption
• LED indicator for connection status

Industrial Case and Installation:

• IP30 metal case
• DIN-rail/desktop design
• Power requirement: 9~36V DC
• Supports EFT protection for 1.5KV DC power and
• 15KV DC Ethernet ESD protection
• -35 to 75 degrees C operating temperature

Digital Input and Digital Output:

• 2 digital input (DI)
• 1 digital output (DO)
• 1 relay

Advanced Features:

• Supports NAT, demilitarized zone (DMZ), port forwarding and virtual IP mapping
• Supports VLAN to improve the performance of a network or apply appropriate security features
• Supports static routing and dynamic routing for gateway and router operating modes
• Supports QoS to manage WAN bandwidth
• Supports PPTP, L2TP, OpenVPN, IPSec and GRE VPN modes
• Supports IPSec (3DES, AES128, AES256, MD5, SHA1, SHA2-256, SHA2-512)
• Supports TCP, UDP, TCP Server and Modbus TCP
• Supports Dynamic DNS and PLANET DDNS
• Provides Firewall and access policy functions
• Supports WAN connection types: DHCP-4G, DHCP Client, Static IP, PPPoE Client, 3G Link1, 3G Link 2, DHCP-Backup 4G
• Secures network connection

  • WAN access
  • URL filter
  • Packet filter
  • MAC filter

Management:

• Management interfaces

  • Console/Telnet Command Line interface
  • Web user interface management
  • SNMP v1, v2c
  • SSH secure access
• Keep Alive (schedule reboot)
• System Maintenance

  • Firmware upload via HTTP
  • Reset button for system reboot or reset to factory default
  • Configuration backup and restore
• System log
• Remote system log
• NTP (Network Time Protocol) client support
• Support CMS to manage multiple devices
