UniFi Pro XG 10 PoE 802.3at/bt 10 Gbit Switch, Layer3 Etherlighting™
Compact desktop/wall-mountable, professional-grade 8-port, Layer 3 Etherlighting™ PoE++ switch with 8x 10 GbE and 2x 10G SFP+ ports.
*Pair with UniFi Enterprise Patch Cable for optimal brightness.
Available stock:
Article number:
USW-PRO-XG-8-POE
Manufacturer number:
USW-PRO-XG-8-POE
Manufacturer page:
UBIQUITI
EAN:
0810177160144
- Etherlighting™ ports that illuminate to indicate port location, speed/link, and native VLAN/network*
- 8x 10 GbE PoE++ ports
- 2x 10G SFP+ ports
- 155W total PoE availability
- Versatile desktop and wall, mounting
Compact desktop/wall-mountable, professional-grade 8-port, Layer 3 Etherlighting™ PoE++ switch with 8x 10 GbE and 2x 10G SFP+ ports.
*Pair with UniFi Enterprise Patch Cable for optimal brightness.
Technical properties
10 Gigabit Ports, PoE:
8
19-inch Rackmount:
No
Case material:
SGCC Steel
Certificate:
CE, FCC, IC
DHCP:
Yes
Design:
Desktop
Dimensions:
210.4 x 173.8 x 43.7 mm
ESD/EMP Protection:
Air ± 30 kV / Contact ± 30 kV
Ext. Temperature Range:
No
Fanless:
No
Forwarding Rate:
149 Mpps
IPv4 Routing:
12000 Routes
MAC Address Table:
32000
Main Speed:
10 Gbit Copper
Managed:
Managed
Management:
Ethernet
Mounting:
Desktop, Wall mountable
Network Ports:
8-Port
Number of Ports:
8 - 15
Operating Conditions:
-5°C - +40°C
Operating Humidity:
10 - 90%, non-condensing
Packet Buffer:
2 MB
PoE Budget:
≤199 Watts
PoE Ports:
8
PoE Power Budget:
155 W
PoE Standard:
IEEE 802.3 af/at/bt
PoE Support:
Yes
Port Speed, RJ45:
10 Gbit
Power Consumption max.:
61 W / 220 W
Redundant PSU:
No
SFP+ Ports:
2
SFP Ports:
-
Stackable:
Yes
Switch Capacity:
200 Gbps
Total Non-Blocking Throughput:
100 Gbps
Uplink Speed:
10 Gbit Fiber
max. Number of VLANs:
1000
max. Power consumption per Port, PoE:
15.4 W
max. Power consumption per Port, PoE+:
30 W
