netPower 15FR 18-Port Outdoor Switch, 15x reverse PoE Ports, 2x SFP
- CRS318-1Fi-15Fr-2S-OUT - netPower 15FR
- 16x 10/100 Ethernet ports
- 2x SFP ports
- Passive PoE
- MicroTik SwOS or Router OS
With netPower 15FR switch you can forget about expensive GPON base stations and optical splitters. This switch is a part of our GPEN concept - aimed to bring the speed and versatility of fiber networking while using the advantages of Ethernet. It is an easy to deploy, low-cost way for any ISP to deliver the Internet to individual apartments.
You dont have to worry about power options in the attic or the utility room netPower 15FR has 15 reverse PoE ports. Depending on your setup, netPower can draw the necessary power even from a single client! Ethernet port 15 can power other PoE capable devices with the same voltage as applied to the unit.
There are two SFP ports for fiber connectivity. The outdoor enclosure allows you to install this switch in all kinds of environments from damp attics to elevator shafts and different poles with hose clamps. netPower 15FR bringing the cost down and the speed up!
netPower 15FR has a non-blocking throughput of 3.6 Gbps, switching capacity of 7.2 Gbps and forwarding rate of 5.4 Mpps.
The power supply is NOT included with the product- must be purchased separately.
Available stock:
Article number:
CRS318-1FI-15FR-2S-OUT
Manufacturer number:
CRS318-1Fi-15Fr-2S-OUT
Manufacturer page:
MIKROTIK
EAN:
4752224002181
- CRS318-1Fi-15Fr-2S-OUT - netPower 15FR
- 16x 10/100 Ethernet ports
- 2x SFP ports
- Passive PoE
- MicroTik SwOS or Router OS
With netPower 15FR switch you can forget about expensive GPON base stations and optical splitters. This switch is a part of our GPEN concept - aimed to bring the speed and versatility of fiber networking while using the advantages of Ethernet. It is an easy to deploy, low-cost way for any ISP to deliver the Internet to individual apartments.
You dont have to worry about power options in the attic or the utility room netPower 15FR has 15 reverse PoE ports. Depending on your setup, netPower can draw the necessary power even from a single client! Ethernet port 15 can power other PoE capable devices with the same voltage as applied to the unit.
There are two SFP ports for fiber connectivity. The outdoor enclosure allows you to install this switch in all kinds of environments from damp attics to elevator shafts and different poles with hose clamps. netPower 15FR bringing the cost down and the speed up!
netPower 15FR has a non-blocking throughput of 3.6 Gbps, switching capacity of 7.2 Gbps and forwarding rate of 5.4 Mpps.
The power supply is NOT included with the product- must be purchased separately.
Technical properties
100 MBit Ports:
16
CPU:
98DX224S
CPU Architecture:
ARM 32bit
CPU Temperature Monitor:
Yes
CPU core count:
1
CPU nominal frequency:
800 MHz
Certificate:
CE/RED, EAC, ROHS
Current Monitor:
Yes
Design:
Various
Dimensions:
304 x 212 x 71 mm
Ext. Temperature Range:
Yes
Fanless:
Yes
Licence Level:
5
Main Speed:
1 Gbit Copper
Managed:
Managed
Number of Ports:
16 - 23
Operating Conditions:
-40°C - +70°C
Operating System:
RouterOS / SwitchOS
PoE Input Voltage:
18 - 57V DC
PoE Standard:
IEEE 802.3 Passive PoE
PoE Support:
Yes
PoE in:
Passive PoE
PoE out:
15
Power Consumption:
29 W
Power Jack:
DC, PoE-In
Redundant PSU:
Yes
SFP 100/1000Mbps Ports:
2
Size of RAM:
256 MB
Stackable:
No
Storage Type internal:
16 MB Flash
Uplink Speed:
1 Gbit Fiber
