UniFi WiFi 7 Pro Outdoor Access Point, 300 Client-Support, 8.6 Gbps
All-weather IP67 WiFi 7 AP with 6 spatial streams, integrated directional super antenna, and articulation mounting bracket.
Available stock:
Article number:
U7-PRO-OUTDOOR
Manufacturer number:
U7-PRO-OUTDOOR
Manufacturer page:
UBIQUITI
EAN:
0810084698730
- WiFi 7
- 6 spatial streams
- 465 m² (5,000 ft²) open space coverage with the integrated directional super antenna
- Software-switchable from internal directional to included external omni antennas
- 300+ connected devices
- Powered using PoE+
- 2.5 GbE uplink
- Versatile wall and pole mounting
- Weatherproof (outdoor exposed)
All-weather IP67 WiFi 7 AP with 6 spatial streams, integrated directional super antenna, and articulation mounting bracket.
Technical properties
2.5 Gbit Ports:
1
Antenna (build in):
Directional
Antenna (external):
optional
Antenna Connector:
2x RP-SMA
Antenna Gain dBi:
2.4 GHz: 8 dBi / 6 dBi, 5 GHz: 11 dBi / 8 dBi
Beamwidth:
90°
Case material:
UV Resistance Polycarbonate, AluminumAlloy
Certificate:
CE
Dimensions:
170 x 208 x 66.5 mm / 170 x 208 x 121.8 mm
Field of application:
Indoor
Frequency:
2.4 GHz & 5 GHz
MIMO 2.4 GHz:
2x2
MIMO 5 GHz:
4x4
Management:
Ethernet
Max. TX Power:
2.4 GHz: 23 dBm / 5 GHz: 29 dBm
Mounting:
Pole Mount, Ø 25 - 63.5 mm, Ceiling Mount
Operating Conditions:
-30°C - +60°C
Operating Humidity:
5 - 95%, non-condensing
Power Consumption max.:
21 W
Power Supply:
PoE+
Power Supply:
UniFi Switch (PoE)
QoS:
Per-User Rate Limiting
SSID per Antenna / Total:
8
Safety Class:
IP66, IPX6
Security:
WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK)
Transfer Rate 2.4 GHz:
688 Mbps
Transfer Rate 5 GHz:
8.6 Gbps
VLAN:
802.1Q
WLAN 2.4 GHz Generation:
WiFi 6
WLAN 5 GHz Generation:
WiFi 7
WLAN Standard:
IEEE 802.11 a/b/g/n/ac/ax/be
Wind load resistance:
74.6 N @ 200 km/h
Wireless Clients:
300+
