QuSpot for RUTX09, IP67 Outdoor Enclosure w/ LTE Omni- & GPS Antenna
- Integrated Outdoor Multi-Band High-Power LTE Omni-Antenna
- GPS Antenna
- Place to install Teltonika RUTX09 (All-in-One)
- Up to 4 dBi LTE Antenna Gain
- IP67
- Passive-PoE Support
QuSpot omni LTE antenna for Teltonika RUTx09 router is a perfect outdoor device for mobile and fixed installations like industrial, CCTV, hotspots, yachts, boats, campers, RV etc. It has embedded GPS antenna. If you use RUTx09 with QuSpot antenna, you get an integrated complete solution with embedded router and multi band antennas in one enclosure.
Available stock:
Article number:
AX09S
Manufacturer number:
QuSpot für RUTx09, IP67 Outdoor Gehäuse mit LTE + GPS Antenn
EAN:
5907772035047
- Integrated Outdoor Multi-Band High-Power LTE Omni-Antenna
- GPS Antenna
- Place to install Teltonika RUTX09 (All-in-One)
- Up to 4 dBi LTE Antenna Gain
- IP67
- Passive-PoE Support
QuSpot omni LTE antenna for Teltonika RUTx09 router is a perfect outdoor device for mobile and fixed installations like industrial, CCTV, hotspots, yachts, boats, campers, RV etc. It has embedded GPS antenna. If you use RUTx09 with QuSpot antenna, you get an integrated complete solution with embedded router and multi band antennas in one enclosure.
Technical properties
Dimensions:
160 x 160 x 240 mm
Impedance:
50 Ohms
LTE Antenna Gain DBI:
2 dBi / 4 dBi
LTE Beamwidth:
360° / 35° ±5°
LTE Frequency:
0.694 - 0.96 GHz / 1.7 - 2.2 GHz / 2.2 - 2.7 GHz
LTE Polarization:
Vertical
LTE VSWR:
<1.70, max. <2.00 / 1.60, max. <2.0
Material:
ABS, Aluminium, PTFE
Operating Conditions:
-40°C - +75°C
Polarization:
Vertical
Safety Class:
IP67
