Industrial LTE CAT M1 / NB-IoT / EGPRS Gateway, Digital I/O, RMS Support
- Mobile: 4G/LTE (Cat M1), NB-IoT, 2G
- CPU: Qualcomm, MIPS 24Kc, 650 MHz
- Memory: 16 MBytes Flash, 64 MBytes RAM
- Powering option: 16pin terminal, 9-30 VDC
- SIM: 2 x Internal SIM holders (2FF)
- Antenna connectors: 1 x SMA for mobile, 1 x SMA for GPS
- Ethernet: 1 x 10/100 Ethernet port
- GNSS: GPS, GLONASS, BeiDou, Galileo, QZSS
- Inputs/Outputs: On 16pin socket:
- 3 x Digital input/Digital open collector output (configurable)
- 1 x Analog input
- Serial: 1 x RS232, 1 x RS485
- Status LEDs: 3 x Connection type, 3 x Signal strength, 2 x Ethernet, 1 x Power
- Operating temperature: -40 °C to 75 °C
- Housing: Aluminium housing with DIN rail mounting option
- Dimensions (W x H x D): 83 x 25 x 74 mm
- Weight: 165 g
Software:
- Operating system: RutOS (OpenWrt based Linux OS)
- Mobile features: Multiple PDN, Auto APN, Band lock, SIM switch, Operator black/white list, Data/SMS limits
- Network protocols: TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSLv3, TLS 1.3, ARP, PPP, DHCP, Telnet
- Monitoring and Management: WEB UI, CLI, SSH, SMS, TR-069, SNMP, JSON-RPC, MQTT, RMS
- Connection monitoring: Ping Reboot, Wget reboot, Periodic Reboot, LCP and ICMP for link inspection
- Cloud solutions: RMS, FOTA, Telenor, Azure IoT Hub, Cloud of Things, Cumulocity, ThingWorx
- NTP: NTP Server, NTP Client, Sync with: External NTP server, GNSS, Mobile operator
- GNSS: NMEA forwarding, AVL, Geofencing
- Modbus: TCP slave, TCP master, RTU master, RTU gateway, Modbus over MQTT
- Serial: Console, Over IP, Modem, NTRIP, Modbus
- Administration: Multi user, Configuration profiles, Diagnostics, logs, Configuration backup
TRM255 is an Industrial Cellular Gateway with multiple LPWAN connectivity options. This gateway is very flexible, because it is equipped with Ethernet, Serial (RS232 + RS485) interfaces and multiple Inputs/Outputs. It features NB-IoT, LTE Cat-M1 and is backwards compatible to EGPRS (2G). Because of multiple cellular connectivity options, it offers cost-efficient and scalable way to upgrade a large amount of legacy infrastructure or implement new long-term M2M connectivity projects. Finally, location positioning technology (GNSS) and Dual-SIM functionality along with compatibility with Teltonika Remote Management system will make sure that your infrastructure is not only reliably connected, but also easy to monitor and control.
Available stock:
Article number:
TRB255
Manufacturer number:
Teltonika Industrial cellular LTE CAT M1 / NB-IOT / EGPRS Ga
Manufacturer page:
TELTONIKA
EAN:
4779027312767
- Mobile: 4G/LTE (Cat M1), NB-IoT, 2G
- CPU: Qualcomm, MIPS 24Kc, 650 MHz
- Memory: 16 MBytes Flash, 64 MBytes RAM
- Powering option: 16pin terminal, 9-30 VDC
- SIM: 2 x Internal SIM holders (2FF)
- Antenna connectors: 1 x SMA for mobile, 1 x SMA for GPS
- Ethernet: 1 x 10/100 Ethernet port
- GNSS: GPS, GLONASS, BeiDou, Galileo, QZSS
- Inputs/Outputs: On 16pin socket:
- 3 x Digital input/Digital open collector output (configurable)
- 1 x Analog input
- Serial: 1 x RS232, 1 x RS485
- Status LEDs: 3 x Connection type, 3 x Signal strength, 2 x Ethernet, 1 x Power
- Operating temperature: -40 °C to 75 °C
- Housing: Aluminium housing with DIN rail mounting option
- Dimensions (W x H x D): 83 x 25 x 74 mm
- Weight: 165 g
Software:
- Operating system: RutOS (OpenWrt based Linux OS)
- Mobile features: Multiple PDN, Auto APN, Band lock, SIM switch, Operator black/white list, Data/SMS limits
- Network protocols: TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSLv3, TLS 1.3, ARP, PPP, DHCP, Telnet
- Monitoring and Management: WEB UI, CLI, SSH, SMS, TR-069, SNMP, JSON-RPC, MQTT, RMS
- Connection monitoring: Ping Reboot, Wget reboot, Periodic Reboot, LCP and ICMP for link inspection
- Cloud solutions: RMS, FOTA, Telenor, Azure IoT Hub, Cloud of Things, Cumulocity, ThingWorx
- NTP: NTP Server, NTP Client, Sync with: External NTP server, GNSS, Mobile operator
- GNSS: NMEA forwarding, AVL, Geofencing
- Modbus: TCP slave, TCP master, RTU master, RTU gateway, Modbus over MQTT
- Serial: Console, Over IP, Modem, NTRIP, Modbus
- Administration: Multi user, Configuration profiles, Diagnostics, logs, Configuration backup
TRM255 is an Industrial Cellular Gateway with multiple LPWAN connectivity options. This gateway is very flexible, because it is equipped with Ethernet, Serial (RS232 + RS485) interfaces and multiple Inputs/Outputs. It features NB-IoT, LTE Cat-M1 and is backwards compatible to EGPRS (2G). Because of multiple cellular connectivity options, it offers cost-efficient and scalable way to upgrade a large amount of legacy infrastructure or implement new long-term M2M connectivity projects. Finally, location positioning technology (GNSS) and Dual-SIM functionality along with compatibility with Teltonika Remote Management system will make sure that your infrastructure is not only reliably connected, but also easy to monitor and control.
Technical properties
100 MBit Ports:
1
Antenna Connector:
2x SMA
CPU:
Qualcomm, MIPS 24Kc, 650 MHz
Case material:
Aluminum Alloy
Cellular Network:
4G/LTE (Cat M1), NB-IoT, 2G
Dimensions:
83 x 25 x 74 mm
Input digital:
3
Interfaces:
Ethernet / LTE
LTE Category:
Cat-M1/NB-IoT
Main Speed:
100 Mbit
Management:
WEB UI, CLI, SSH, SMS, TR-069, SNMP, JSON-RPC, MQTT, RMS
Mobile Standard:
2G/4G
Mounting:
DIN-Rail
Operating Conditions:
-40°C - +75°C
Operating System:
RutOS
Port Speed, RJ45:
10 Mbit/100 Mbit
Power Consumption max.:
<1.2W / <5.0W
Power Jack:
16-Pin Terminal
SIM Slots:
2
Serial Interface Type:
RS-232, RS-485
Size of RAM:
64 MB
Storage Type internal:
16 MB Flash
WLAN:
No
