Chateau LTE7 ax Kit Dual-Band Router, 1x 2.5Gbit, 4x 1GBit, LTE7 Support

Chateau LTE7 ax keeps the same powerful hardware, sleek design, and Wi-Fi 6 performance – but now features an LTE Category 7 modem, expanded frequency support, and a significantly lower price than the previous LTE6 ax version.

Product Quantity: Enter the desired amount or use the buttons to increase or decrease the quantity.
Stk
Available stock:
Article number: CHATEAU LTE7 AX
Manufacturer number: S53UG+5HaxD2HaxD-TC&R11e-LTE7
Manufacturer page: MIKROTIK
  • S53UG+5HaxD2HaxD-TC&R11e-LTE7
  • Dual 2.4 GHz & 5 GHz AP
  • 802.11b/g/n/ax Dual-Chain Support
  • LTE7 Support
  • 2 & 4 dBi Antenna Gain
  • 802.11 a/b/g/n/ac
  • 1x 2.5 Gbit Ethernet Ports
  • 5x 1 Gbit Ethernet Ports

Chateau LTE7 ax keeps the same powerful hardware, sleek design, and Wi-Fi 6 performance – but now features an LTE Category 7 modem, expanded frequency support, and a significantly lower price than the previous LTE6 ax version.

Technical properties
1 GBit Ports:
4
2.5 Gbit Ports:
1
3G Bands:
1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 8 (900MHz)
3G Category:
R8 (DL: 42.2 Mbps; UL: 5.76 Mbps)
Antenna Gain dBi:
2.4 GHz: 3 dBi / 5 GHz: 6 dBi
CPU:
IPQ-6010
CPU Architecture:
ARM 64bit
CPU core count:
4
CPU nominal frequency:
1.8 GHz
Chipset:
IPQ-6010
Design:
Desktop
Dimensions:
240 x 156 x 44 mm
LTE Category:
7 (DL: 300 Mbps; UL: 100 Mbps)
LTE FDD Bands:
1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 7 (2600MHz) / 8 (900 MHz) / 20 (800MHz) / 28 (700MHz) / ...
LTE TDD Bands:
38 (2600MHz) / 40 (2300MHz) / 41 (2500MHz)
Licence Level:
4
MIMO:
2x2 / 1x1
Manufacturer Number:
S53UG+5HaxD2HaxD-TC&R11e-LTE7
Number of Ports:
1 - 7
Operating Conditions:
-40°C - +70°C
Operating System:
RouterOS v7
Power Consumption:
21.5 W
Power Jack type:
DC Jack
Power Supply:
12 - 28V DC
SIM Slots:
1x Micro SIM
Size of RAM:
1 GB DDR3L
Storage Type internal:
128 MB NAND
USB Ports:
1
USB Slot Type:
USB Typ A
WAN Connection Type:
Cellular Radio
WLAN:
Yes
WLAN Standard:
IEEE 802.11 a/b/g/n/ac/ax
eSIM:
No
