UniFi Enterprise E7 Wifi 7 Access Point, 10 Streams, 10 GBit, 6 GHz
Enterprise-grade indoor access point with 10-stream WiFi 7 performance, a 10 GbE uplink, and a redundant GbE port for high availability.
*Available in FCC/IC region only.
Available stock:
- For project prizes please fill in the following form:
- Link: https://bit.ly/3y7vq1u
- Link: https://bit.ly/3y7vq1u
- WiFi 7 with 6 GHz support
- 10 spatial streams
- Real-time spectral analysis for enhanced channel selection
- Dedicated spectral analyzer radio
- Long-range 6 GHz performance with AFC*
- 185 m² (2,000 ft²) coverage
- 1,000+ connected devices
- 1x 10 GbE RJ45 port
- 1x GbE RJ45 port for power & data redundancy
- Backwards compatible mounting system
- Powered using PoE++
Enterprise-grade indoor access point with 10-stream WiFi 7 performance, a 10 GbE uplink, and a redundant GbE port for high availability.
*Available in FCC/IC region only.
Technical properties
1 GBit Ports:
1
10 GBit Ports:
1
Antenna Gain dBi:
2.4 GHz: 5.0 dBi, 5 GHz: 6.0 dBi, 6 GHz: 6.0 dBi
Antenna Type:
Omni-directional
Case material:
UV-stabilized Polycarbonate, Aluminium Alloy
Certificate:
CE, FCC, IC
Dimensions:
250 x 250 x 43.5 mm
Enterprise Product:
Yes
Field of application:
Indoor
Frequency:
2.4 GHz & 5 GHz & 6 GHz
MIMO 2.4 GHz:
2x2
MIMO 5 GHz:
4x4
MIMO 6GHz:
4x4
Management:
Ethernet
Max. TX Power:
2.4 GHz: 23 dBm / 5 GHz: 30 dBm / 6 GHz: 24 dBm / 30 dB,
Mounting:
Ceiling / Wall Mounting
Operating Conditions:
-30°C - +50°C
Operating Humidity:
5 - 95%, non-condensing
Power Consumption max.:
43 W
Power Supply:
PoE++
Power Supply:
UniFi Switch (PoE)
SSID per Antenna / Total:
8
Security:
WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK)
Supported Input Voltage:
42,5 - 57V DC
Transfer Rate 2.4 GHz:
688 Mbps
Transfer Rate 5 GHz:
8.6 Gbps
Transfer Rate 6GHz:
11.5 Gbps
VLAN:
802.1Q
WLAN Standard:
IEEE 802.11 a/b/g/n/ac/ax/be
Wireless Clients:
1,000+
