UISP airFiber 60 XR, 15+ km, Multi-Gigabit, 60 GHz Bridge with SFP+ Support
Multi-gigabit, 60 GHz bridge designed to create long-distance links and deliver 5.4 Gbps total throughput (2.7 Gbps duplex) over them.
It's also equipped with a 5 GHz backup radio for operational redundancy, as well as a Bluetooth radio to simplify setup via the UISP® Mobile app.
Available stock:
- 5 GHz backup radio
- Link range: 15+ km
- 1x 10G SFP+ port
- Integrated GPS
- Link planning support via the ISP Design Center
Multi-gigabit, 60 GHz bridge designed to create long-distance links and deliver 5.4 Gbps total throughput (2.7 Gbps duplex) over them.
It's also equipped with a 5 GHz backup radio for operational redundancy, as well as a Bluetooth radio to simplify setup via the UISP® Mobile app.
Technical properties
1 GBit Ports:
1
Band:
57 - 71 GHz
CPU:
Quad Core ARM Cortex A53 1.4 GHz
Case material:
UV-stabilized Polycarbonate, Steel
Certificate:
FCC, IC, CE
Dimensions:
779 x 664 x 383 mm
Elevation Beamwidth:
± 1°
Encryption:
WPA2-PSK (AES)
Field of application:
Outdoor
Frequency:
60 Ghz
GPS:
Yes
Maximum Distance:
15+ km
Modes / Function:
PtP only
Mounting:
Pole Mount, Ø 40-80 mm
Operating Conditions:
-40°C - +55°C
Operating Humidity:
5 - 95%, non-condensing
Operating System:
airOS®
Power Consumption max.:
24 W
Power Supply:
Passive-PoE
Power Supply:
48V DC, 0.65A PoE Adapter
SFP+ Ports:
1
Safety Class:
IPX6
Size of RAM:
DDR3L 1GB
Transfer Rate:
2.5+ Gbps
WLAN Standard:
IEEE 802.11ad
Wind load resistance:
422 N @ 200 km/h
Wireless Clients:
1
Downloads
Datenblatt_en.pdf
