IP30 Industrial 5-Port 1Gbit PoE+ unmanaged Switch, -40°C - +75°C
TSW100 – 5-port, unmanaged full Gigabit Ethernet switch supporting Power-over-Ethernet (802.3af and 802.3at standards). This device is classified as power source equipment (PSE), and when used in this way, TSW100 switch enables centralization of the power supply, providing up to 30 watts of power per port and reducing the effort for installing power. It has 10/100/1000 Mbps Ethernet ports to provide an economical high-bandwidth solution for your industrial Ethernet network.
Available stock:
Article number:
TSW100
Manufacturer number:
TSW100010000
Manufacturer page:
TELTONIKA
EAN:
4779027312828
- 5-port 10/100/1000BASE-T Gigabit RJ45 copper with IEEE 802.3at/af PoE Injector (Port 1 to Port 4)
- Bandwidth (Non-blocking): 10 Gbps
- Total PoE Power Budget: 120 W
- Full aluminum housing
- DIN rail or wall mounting
- -40 °C to +75 °C
TSW100 – 5-port, unmanaged full Gigabit Ethernet switch supporting Power-over-Ethernet (802.3af and 802.3at standards). This device is classified as power source equipment (PSE), and when used in this way, TSW100 switch enables centralization of the power supply, providing up to 30 watts of power per port and reducing the effort for installing power. It has 10/100/1000 Mbps Ethernet ports to provide an economical high-bandwidth solution for your industrial Ethernet network.
Technical properties
1 GBit Ports:
1
1 GBit Ports, PoE:
4
Case material:
Aluminum Alloy
Design:
DIN Rail
Dimensions:
115 x 32 x 95 mm
Jumbo Frame:
9216 bytes
MAC Address Table:
2 K
Main Speed:
1 Gbit Copper
Managed:
Unmanaged
Mounting:
DIN-Rail, wall-mount
Network Ports:
5-Port
Number of Ports:
1 - 7
Operating Conditions:
-40°C - +75°C
Operating Humidity:
10 - 90%, non-condensing
Packet Buffer:
128 KB
PoE Power Budget:
120 W
PoE Standard:
IEEE 802.3 af/at
PoE Support:
Yes
PoE in:
No
PoE out:
Yes
Port Speed, RJ45:
10 Mbit/100 Mbit/1 Gbit
Power Consumption max.:
2.0W / 9.0W / 129W (PoE)
Power Jack:
4-Pin industrial DC socket
Power Supply:
7 - 58V DC
SFP Ports:
-
Safety Class:
IP30
Total Non-Blocking Throughput:
10 Gbps
max. Power consumption per Port, PoE:
30 W
