Industrie 4G/LTE Dual SIM Router, fpr IoT Applications, GNSS, RS485/232
Cellular 4G router for industrial IoT applications, supporting serial interfaces RS232 and RS485, MQTT, BACnet, I/Os, Ethernet, and more. This cellular router is equipped with GNSS and failsafe features such as Dual SIM, auto-failover, and backup WAN.
- Connectivity: 4G LTE (Cat 4), 3G, 2G
- Dual-Sim: Auto-failover, backup WAN, and more switching scenarios
- Interfaces & Protocols: Serial interfaces (RS232 & RS485), MQTT, BACnet, OPC UA, I/Os, Ethernet, and more
- GNSS: NTRIP, location services and time synchronization
Available stock:
Article number:
RUT906
Manufacturer number:
RUT906000000
Manufacturer page:
TELTONIKA
EAN:
4779051840830
- 4G (LTE) – Cat 4 up to 150 Mbps
- 3G – Up to 42 Mbps
- 2G – Up to 236.8 kbps
- WiFi – IEEE 802.11b/g/n, Access Point (AP), Station (STA)
- Ethernet – 4 ports
- SMS
- WAN Failover
- Dual SIM
- RMS - Compatible with Teltonika Remote Management System
Cellular 4G router for industrial IoT applications, supporting serial interfaces RS232 and RS485, MQTT, BACnet, I/Os, Ethernet, and more. This cellular router is equipped with GNSS and failsafe features such as Dual SIM, auto-failover, and backup WAN.
- Connectivity: 4G LTE (Cat 4), 3G, 2G
- Dual-Sim: Auto-failover, backup WAN, and more switching scenarios
- Interfaces & Protocols: Serial interfaces (RS232 & RS485), MQTT, BACnet, OPC UA, I/Os, Ethernet, and more
- GNSS: NTRIP, location services and time synchronization
Technical properties
100 MBit Ports:
4
Antenna Connector:
3x SMA, 2x RP-SMA
CPU nominal frequency:
580 MHz
Case material:
Aluminum Alloy
Category:
EU Power Supply
Design:
DIN Rail
Digital Input / Output:
3 / 1
Dimensions:
109.5 x 50 x 100 mm
Firewall Function:
OpenVPN, IPsec, GRE, PPTP, L2TP, Stunnel, DMVPN, SSTP, ZeroTier, WireGuard
Flash Memory:
16 MB SPI
Frequency:
2.4 GHz
GPS:
Yes
GSM/GPRS/EDGE Support:
Yes
LEDs:
Ethernet, Power, Signal Strength
LTE Category:
Cat 4
LTE Support:
Yes
Manufacturer Number:
RUT906000000
Mobile Standard:
2G/3G/4G
Mounting:
DIN-Rail
Network Ports:
4-Port
Number of Ports:
1 - 7
Operating Conditions:
-40°C - +75°C
Operating Humidity:
10 - 90%, non-condensing
Port Speed, RJ45:
10 Mbit/100 Mbit
Power Consumption:
<7W
Power Consumption max.:
<2.0W / 7.0W
Power Jack:
4-Pin industrial DC socket
Power Supply:
100 - 240 VAC / 9 - 30 VDC
SFP Ports:
-
Safety Class:
IP30
Security:
WPA3-EAP, WPA3-SAE, WPA2-Enterprise-PEAP, WPA2-PSK, WEP; AES-CCMP, TKIP, Auto Cipher modes, clie ...
Serial Interface Type:
RS-232 / RS-485
Size of RAM:
128MB DDR2
WAN Connection Type:
LTE / 4G
WLAN:
Yes
WLAN Standard:
IEEE 802.11 b/g/n
