Industrial rugged LTE 5G 3.4Gbps Modem, IP30, -40°C - +75°C
The TRM500 is a compact and lightweight 5G modem with ultra-high cellular speeds of up to 3.4 Gbps. This industrial-grade 5G modem features backward compatibility with 4G (Cat 19) and 3G networks, four SMA antennas for enhanced coverage, DIN rail mounting options, and a USB Type-C interface for simultaneous network data and powering.
Available stock:
Article number:
TRM500
Manufacturer number:
TRM500000000
Manufacturer page:
TELTONIKA
EAN:
4779051841455
- 5G - Ultra-high cellular speeds of up to 3.4 Gbps
- Future-Proofing - Backward compatible with 4G (Cat 19) and 3G
- USB Type-C - For simultaneous network data and powering
- Campact - Small size, easy Installation
- Mobile module: 5G Sub-6GHz SA: 2.4Gbps (DL)/900Mbps (UL); 5G NSA Sub-6GHz: 3.4Gbps DL (4x4 MIMO)/ 550 Mbps UL (2x2); 4G (LTE-FDD) – LTE Cat 19 1.6Gbps DL, 200Mbps UL; 3G – 42 Mbps DL, 5.76Mbps UL
- 3GPP Release: Release 16
- Connector: 1 x 4-pin industrial DC power socket
- 1 x USB Type-C
- 1 x SIM slot (Mini SIM – 2FF)
- Antenna: 4 x SMA for Mobile
- -40 °C to 75 °C
- IP30
The TRM500 is a compact and lightweight 5G modem with ultra-high cellular speeds of up to 3.4 Gbps. This industrial-grade 5G modem features backward compatibility with 4G (Cat 19) and 3G networks, four SMA antennas for enhanced coverage, DIN rail mounting options, and a USB Type-C interface for simultaneous network data and powering.
Technical properties
Antenna Connector:
4x SMA
Case material:
Anodized Aluminum
Cellular Network:
5G NR(SA/NSA) / 4G (LTE-FDD) / 4G (LTE-TDD) / 3G
Dimensions:
83 x 25 x 85.4
Interfaces:
5G
LTE Category:
CAT 19
Mobile Standard:
3G/4G/5G
Mounting:
DIN Rail, Wall Mount
Operating Conditions:
-40°C - +75°C
Operating Humidity:
10 - 90%, non-condensing
Power Consumption max.:
<12 W
Power Jack:
micro USB
Power Supply:
9 - 30V DC, USB
SIM Slots:
mini SIM (2FF)
Safety Class:
IP30
Security Standards:
EN IEC 62311:2020, EN IEC 62368-1:2018
WLAN:
No
