airFiber 60 HD, Multi-Gigabit, 60 GHz Bridge w/ SFP+ Support, 2 km Link Range

The airFiber 60 HD (AF60 HD) is a 60 GHz radio designed to create superior mid-range, point-to-point (PtP) links up to 2 km. The AF60 HD delivers low-interference, low-latency throughput within the 60 GHz spectrum. Compact and highly durable, the AF60 HD also features integrated GPS and a Bluetooth management radio to simplify setup, configuration, and monitoring. This bridge is ideal for ISPs looking to maximize signal linking with cost-effective equipment.

Product Quantity: Enter the desired amount or use the buttons to increase or decrease the quantity.
Stk
Available stock:
Article number: AF60-HD
Manufacturer number: AF60-HD
Manufacturer page: UBIQUITI
EAN: 0810010076113
  • Low-interference 60 GHz spectrum
  • Up to a 2 km link range
  • Supports channel bonding to achieve up to a 6 Gbps throughput rate
  • 1x 10G SFP+ port
  • Terragraph-certified
  • Integrated GPS
  • Link planning support via ISP Design Center
  • Simple, Bluetooth-powered setup with the UISP™ Mobile app

The airFiber 60 HD (AF60 HD) is a 60 GHz radio designed to create superior mid-range, point-to-point (PtP) links up to 2 km. The AF60 HD delivers low-interference, low-latency throughput within the 60 GHz spectrum. Compact and highly durable, the AF60 HD also features integrated GPS and a Bluetooth management radio to simplify setup, configuration, and monitoring. This bridge is ideal for ISPs looking to maximize signal linking with cost-effective equipment.

Technical properties
1 GBit Ports:
1
Application Field:
Point-to-Poinit
Band:
57 - 66 GHz
Beam Angle:
VPOL: 3°, Elevation: 3°
Bluetooth:
Bluetooth v4.0
CPU:
ARM Cortex A72 1.6 GHz
CPU core count:
4
Case material:
Aluminum, UV-stabilized Plastic
Certificate:
FCC, CE, IC, Terragraph
Channel Bandwidth:
2160 MHz / 4320 MHz
Dimensions:
Ø 189 x 89 mm
Encryption:
WPA2-PSK (AES)
Field of application:
Outdoor
Frequency:
60 Ghz
Management Port:
Bluetooth
Operating Conditions:
-40°C - +55°C
Operating Humidity:
5 - 95%, non-condensing
Operating System:
airFiber©
Power Consumption:
29.31 W
Power Supply:
Passive POE
Power Supply:
48V DC, 0.65A PoE GigE Adapter (included)
Range:
2 km
SFP+ Ports:
1
Safety Class:
IPX6
Transfer Rate:
up to 3.8 Gbps / 6 Gbps
WLAN Standard:
IEEE 802.11ad
Wind load resistance:
64 N @ 200 km/h
Wireless Clients:
1
