Abmessungen
42 x 80 x 22 mm (1.65 x 3.15 x 0.87 in)
Anschluss Seriell
DB9 female
Betriebstemperatur
0 - +60°C (32 - 140°F)
Datenrate
300 bps - 115.2 kbps
Eingangsstrom
20 mA @ 5 VDC (with termination disabled)
EMC Standards
EN 55022/24
EMI Standards
CISPR 22, FCC Part 15B Class B
EMS Standards
EN 61000-4-2 (ESD): Contact: 4 kV; Air: 8 kV
EN 61000-4-3 (RS): 80 MHz to 1 GHz: 3 V ...
Gehäuse Material
ABS + PC
Green Produkt
RoHS, CRoHS, WEEE
Lagertemperatur
-20 to 75°C (-4 to 167°F)
Luftfeuchtigkeit
5 bis 95% nicht kondensierend
MTBF
2,272,562 hrs, MIL-HDBK-217F
Serielle Signale RS-232
Tx, Rx, GND (Loop-back wiringRTS to CTS, DTR to DSR and DCD)
Sicherheit Standards
UL 60950-1
Spannungseingang
5 to 12 VDC
