IP30 Industrie 5-Port 10/100/100Mbit unmanaged Hutschienen-Switch, -40°C - +75°C
TSW114 is an affordable way to simplify your connectivity with its plug and play nature and 5 x Gigabit Ethernet ports that provide stable and reliable connectivity for high-bandwidth solutions. The switch has front-facing ports and an integrated DIN rail bracket to enable easy installation across many industrial environments - especially control cabinets.
Lagerbestand:
- 5-Port 10/100/1000 Mbit RJ45-Kupfer
- Passiv-PoE-In (Port 1)
- Bandbreite (non-blocking): 10 Gbps
- Vollaluminiumgehäuse
- Hutschienen- oder Wandmontage
- -40°C bis +75°C
TSW114 is an affordable way to simplify your connectivity with its plug and play nature and 5 x Gigabit Ethernet ports that provide stable and reliable connectivity for high-bandwidth solutions. The switch has front-facing ports and an integrated DIN rail bracket to enable easy installation across many industrial environments - especially control cabinets.
Technische Daten
Hauptgeschwindigkeit:
1 Gbit Kupfer
Portanzahl:
1 - 7
PoE Support:
Ja
Managed:
Unmanaged
Bauform:
Hutschiene
Abmessungen:
113.1 x 27.4 x 80.5 mm
Schutzklasse:
IP30
1 GBit Ports:
4
1 GBit Ports, PoE-In:
1
Betriebstemperatur:
-40°C - +75°C
Gehäuse Material:
Aluminium
Jumbo Frame:
9216 bytes
Leistungsaufnahme max.:
0.3W / 2.3 W
Luftfeuchtigkeit:
10 - 90%, nicht kondensierend
MAC Adressen Table:
2 K
Netzwerk Ports:
5-Port
Packet Buffer:
128 KB
PoE in:
Ja
PoE out:
Nein
Port Speed, RJ45:
10 Mbit/100 Mbit/1 Gbit
SFP Ports:
-
Sicherheit Standards:
EN IEC 62368-1:2020+A11:2020
Strom Anschluss:
2-Pin Terminal Block
Stromversorgung:
9 - 30V DC, PoE
Total Non-Blocking Throughput:
10 Gbps
Zertifikate / Zulassungen:
CE, REACH, RoHS, WEEE, UKCA, FCC, IC, CB, RCM
