5 GHz airPrism Sector, 90°, High Density
- Powerful Performance for High-Density Areas
- 3x 30° Beamwidth Coverage in a MultiPoint Network
- Efficient Footprint for Reduced Tower Costs
The Rocket5ac Prism is designed to deliver maximum spectral efficiency and throughput.
Features
5 GHz Frequency Band:
With plenty of available spectrum, this unlicensed band works well for long-distance links. The Rocket5ac Prism features full-band 5 GHz coverage and
maximizes output power for the US market, meeting strict OOBE requirements.
airView:
Use the real-time spectrum analyzer so you can identify noise signatures and design your wireless links to minimize noise interference.
High Performance:
To take full advantage of its design and capabilities, deploy the Rocket5ac Prism for PtP or PtMP links in high RF noise environments.
airPrism Sector Antenna:
You can mount three Rocket5ac Prism radios on the airPrism 5 GHz 3x30° HD Sector Antenna, model AP-5AC-90-HD, for PtMP links. Each Rocket radio
corresponds with a specific 30° beamwidth and independently transmits and receives.
EMI-Shielded Metal Housing:
Helps protect the Rocket5ac Prism against electromagnetic interference.
Gigabit Ethernet:
Delivers high throughput over its wired connection.
Passive Power over Ethernet (PoE):
24V Passive PoE functionality is included. Both power and data are carried over a single Ethernet cable to the Rocket ac. Use the included PoE Adapter or an optional PoE switch.
Plug and Play Integration:
Every airMAX antenna has a built-in Rocket mount, so no tools are needed to install the Rocket5ac Prism. (airMAX ac antennas are recommended for optimal performance.)
Lagerbestand:
Artikelnummer:
AP-5AC-90-HD
Herstellernummer:
AP-5AC-90-HD
Herstellerseite:
UBIQUITI
EAN:
0810354021947
- Powerful Performance for High-Density Areas
- 3x 30° Beamwidth Coverage in a MultiPoint Network
- Efficient Footprint for Reduced Tower Costs
The Rocket5ac Prism is designed to deliver maximum spectral efficiency and throughput.
Features
5 GHz Frequency Band:
With plenty of available spectrum, this unlicensed band works well for long-distance links. The Rocket5ac Prism features full-band 5 GHz coverage and
maximizes output power for the US market, meeting strict OOBE requirements.
airView:
Use the real-time spectrum analyzer so you can identify noise signatures and design your wireless links to minimize noise interference.
High Performance:
To take full advantage of its design and capabilities, deploy the Rocket5ac Prism for PtP or PtMP links in high RF noise environments.
airPrism Sector Antenna:
You can mount three Rocket5ac Prism radios on the airPrism 5 GHz 3x30° HD Sector Antenna, model AP-5AC-90-HD, for PtMP links. Each Rocket radio
corresponds with a specific 30° beamwidth and independently transmits and receives.
EMI-Shielded Metal Housing:
Helps protect the Rocket5ac Prism against electromagnetic interference.
Gigabit Ethernet:
Delivers high throughput over its wired connection.
Passive Power over Ethernet (PoE):
24V Passive PoE functionality is included. Both power and data are carried over a single Ethernet cable to the Rocket ac. Use the included PoE Adapter or an optional PoE switch.
Plug and Play Integration:
Every airMAX antenna has a built-in Rocket mount, so no tools are needed to install the Rocket5ac Prism. (airMAX ac antennas are recommended for optimal performance.)
Technische Daten
Frequenzband:
5 GHz
Produktfamilie:
Sektor Antenne
Antennen Gewinn dBi:
22
Antennenanschluss:
RSMA
Abmessungen:
32,3cm x 20,2cm x 130,0cm
Frequenzbereich:
5150 MHz - 5850 MHz
Max. VSWR:
1.75:1
Polarisation:
Vertikal + Horizontal
Verstärkung:
22 db
Öffnungswinkel Antenne:
8°
