16-Port 1Gbit 802.3at PoE + 2-Port 1Gbit + 2-Port SFP Desktop Switch, 120W
- 16-port 10/100/1000BASE-T Gigabit RJ45 copper with IEEE 802.3at PoE+ injector function
- 2 10/100/1000BASE-T Gigabit RJ45 copper interfaces
- 2 1000BASE-X SFP interfaces
Power over Ethernet:
Complies with IEEE 802.3at Power over Ethernet end-span PSE
Up to 16 ports of IEEE 802.3af/802.3at devices powered (ports 1~16)
Supports PoE power up to 32 watts for each PoE port, with a total PoE budget of 185W.
Each port supports 54V DC power to PoE powered device
Auto detects powered device (PD)
Supports PD alive function
Circuit protection prevents power interference between ports
Remote power feeding up to 100m in standard mode with 250m in extend mode
Switching:
Hardware-based 10/100/1000Mbps auto-negotiation and auto MDI/MDI-X
Supports IEEE 802.3x flow control in full-duplex mode and backpressure in half-duplex mode
Integrates address look-up engine, supporting 8K absolute MAC addresses
9K jumbo frame supports all speeds (10/100/1000Mbps)
Hardware DIP switch for Standard, VLAN and Extend mode selection;
VLAN mode: Ports 1 to 16 cannot communicate with each other, but can communicate with the uplink ports 17 to 18 and SFP ports 19 to 20
Extend mode: Ports1 to 8 have data rate of 10Mbps. The farthest transmission distance of up to 250 meters and all ports can communicate with each other.
VLAN mode is to isolate ports to prevent broadcast storm and defend DHCP spoofing
Automatic address learning and address aging
Supports Energy-Efficient Ethernet (EEE) function (IEEE 802.3az)
Hardware:
12-inch desktop size, 1U height
LED indicators for system power, per port PoE ready and PoE activity, speed, Link/Act
1 silent fan to provide stable and efficient power performance
Supports contact discharge of ±6KV DC and air distance discharge of ±8KV DC for Ethernet ESD protection
Supports ±6KV surge immunity
Lagerbestand:
- 16-port 10/100/1000BASE-T Gigabit RJ45 copper with IEEE 802.3at PoE+ injector function
- 2 10/100/1000BASE-T Gigabit RJ45 copper interfaces
- 2 1000BASE-X SFP interfaces
Power over Ethernet:
Complies with IEEE 802.3at Power over Ethernet end-span PSE
Up to 16 ports of IEEE 802.3af/802.3at devices powered (ports 1~16)
Supports PoE power up to 32 watts for each PoE port, with a total PoE budget of 185W.
Each port supports 54V DC power to PoE powered device
Auto detects powered device (PD)
Supports PD alive function
Circuit protection prevents power interference between ports
Remote power feeding up to 100m in standard mode with 250m in extend mode
Switching:
Hardware-based 10/100/1000Mbps auto-negotiation and auto MDI/MDI-X
Supports IEEE 802.3x flow control in full-duplex mode and backpressure in half-duplex mode
Integrates address look-up engine, supporting 8K absolute MAC addresses
9K jumbo frame supports all speeds (10/100/1000Mbps)
Hardware DIP switch for Standard, VLAN and Extend mode selection;
VLAN mode: Ports 1 to 16 cannot communicate with each other, but can communicate with the uplink ports 17 to 18 and SFP ports 19 to 20
Extend mode: Ports1 to 8 have data rate of 10Mbps. The farthest transmission distance of up to 250 meters and all ports can communicate with each other.
VLAN mode is to isolate ports to prevent broadcast storm and defend DHCP spoofing
Automatic address learning and address aging
Supports Energy-Efficient Ethernet (EEE) function (IEEE 802.3az)
Hardware:
12-inch desktop size, 1U height
LED indicators for system power, per port PoE ready and PoE activity, speed, Link/Act
1 silent fan to provide stable and efficient power performance
Supports contact discharge of ±6KV DC and air distance discharge of ±8KV DC for Ethernet ESD protection
Supports ±6KV surge immunity
Technische Daten
Hauptgeschwindigkeit:
1 Gbit Kupfer
Höheneinheiten:
1 HE
PoE Standard:
IEEE 802.3 at
Portanzahl:
16 - 23
PoE Support:
Ja
Bauform:
19" Rackmount
Abmessungen:
280 x 180 x 44 mm
1 GBit Ports:
2
1 GBit Ports, PoE:
16
19-Zoll Rackmount:
Ja
Betriebstemperatur:
0°C - 50°C
ESD/EMP Schutz:
Luft ± 8KV; Kontakt ± 6KV
Flow Control:
IEEE 802.3x pause frame for full duplex; back pressure for half duplex
Gehäuse Material:
Metall
Jumbo Frame:
9216 bytes
Leistungsaufnahme max.:
201 W
Luftfeuchtigkeit:
5 - 95%, nicht kondensierend
Lüfter:
1
MAC Adressen Table:
8K
Netzwerk Ports:
18-Port
PoE Gesamtleistung:
185 W
SFP Ports:
2
Stromversorgung:
100 - 240 VAC, 50/60 Hz
Switch Architektur:
Store-and-Forward
Switch Datendurchsatz @ 64 Bytes:
29.76 Mpps
Switch Fabric:
40 Gbps / non-blocking
Zertifikate / Zulassungen:
FCC Part 15 Class A, CE
Überspannungs Schutz:
± 6KV
